    300W N Connector 18GHz HF RF Attenuator For Reducing Power Levels

    Ask Lasest Price
    Brand Name : Vinncom
    Model Number : VN-AT-18G-300W-ONx
    Certification : RoHs ISO9000
    Price : negotiation
    Payment Terms : T/T, L/C, D/A, D/P
    Supply Ability : 300pcs per day
    Delivery Time : depends on quantity
    • Product Details
    • Company Profile

    300W N Connector 18GHz HF RF Attenuator For Reducing Power Levels

    300W N Connector 18GHz HF RF Attenuator For Reducing Power Levels


    • Low standing wave
    • High attenuation accuracy
    • High indicator stability

    Part NumberVN-AT-18G-300W-ONx
    Operating FrequencyDC-18 GHZ
    Impedance ( Ohm )50
    ApplicationIndoor & Outdoor
    Degree of ProtectionIP65
    Handling Power (Watt, max)300W
    InterfaceN Male - N Female
    Operating Temperature ( ℃ )-40 ~ + 80
    Attenuation(dB)102030405060VSWR
    DC-4GHz±0.7±0.8±0.9±0.9±1.0±1.2≤1.20
    DC-8GHz±0.8±0.9±1.0±1.0±1.2±1.4≤1.25
    DC-12.4GHz±0.9±1.0±1.2±1.2±1.4±1.8≤1.35
    DC-18GHz±3.0±1.8±1.5±1.6±1.8±2.0≤1.45
    Dimension (mm)(L×W×H, excl connector)305*110*120mm
    Net Weight (g)
    Packing Dimensions (mm,L×W×H)
    Packing Carton Size (mm,L×W×H)
    ROHS ComplianceYes
